School's Cool

2021 · built with a friend

A 2021 intranet for an Amsterdam mentoring foundation: channels with posts and votes, events, a shared file library, 1:1 chat and role-based admin, behind a Passport login. Built with a friend, and I was the one who integrated it.

Type
Education
Status
Internal

The intranet, 2021. In order: Browser, React 17, one client; then API, Express 4, sessions behind Passport; then MongoDB, Mongoose models and their relations.

Side lane — the services: Socket.IO chat, 1:1 messages; Uploads, S3 and Cloudinary; Mail, transactional, through Gmail.

Fig. 01 — The intranet, 2021
Problem
The foundation needed social features, learning, chat, and files in one place.
Constraint
A first real production system, and quality could not slip mid-delivery.
Decision
Ship the full platform while taking extra courses in parallel to keep the architecture honest.
Outcome
Shipped in 2021 for the foundation's staff and mentors. The e-learning module was later built by another developer. The screens show demo data — the real ones are the foundation's.
A channel: posts, votes and comments — demo data
Fig. 02 — A channel: posts, votes and comments — demo data
An event: banner, attendees and comments — demo data
Fig. 03 — An event: banner, attendees and comments — demo data
The library: uploads with PDF previews — demo data
Fig. 04 — The library: uploads with PDF previews — demo data

Bill of quantities · As-built 2026-11

Item, quantity, and the command that measured it.
ItemQuantity
Mongoose modelsgit ls-tree -r --name-only dev -- server/models | grep -c '.js$'7

Stack used

React 17React Router 5Semantic UIBootstrap 5Socket.IO 4Node.jsExpress 4PassportMongoDBMongoose 5AWS S3CloudinaryNodemailer
